 Medium Decibel Horn/Buzzer |
| |
 |
| Model 31T |
|
Product Sheet
 Listen |
|
|
|
|
| ·The 31T Industrial Horn is a high performance mechanical Horn ideal for life safety applications where medium sound output, low current draw and dependable operation are of critical concern. Available only in 120 Volt AC, 88dB rating |
| High Decibel Horn/Buzzer |
|
| |
 |
| Model 874 |
|
|
Product Sheet
Listen |
|
|
|
|
| ·The 874 Industrial Bell is a high performance mechanical Horn ideal for life safety applications where High sound output, low current draw and dependable operation are of critical concern. The model 874 horn has user adjustable sound output from 72 dB up to a maximum of 101dB. Available in 120 Volt AC or 24 Volts AC |
| High Decibel Horn/Speaker |
|
| |
 |
| Model H5 |
|
|
Product Sheet
|
|
|
|
|
| ·The H5 Horn/Speaker is a high performance mechanical Horn ideal for life safety applications where High sound output, low current draw and dependable operation are of critical concern. The model H5 horn has user adjustable sound output from 72 dB up to a maximum of 92dB. Available in 24 Volts DC. To be used With Tone Generator Module |
| Baffle Speaker |
|
| |
 |
| Model ASW |
|
|
Product Sheet
|
|
|
|
|
| ·The ASQ Baffle Speaker is a high performance Speaker ideal for life safety applications where High sound output, low current draw and dependable operation are of critical concern. The model ASW Speaker has user adjustable sound output from 72 dB up to a maximum of 92dB. Available in 24 Volts DC. To be Used with Tone generator Module |
| Vibrating Bells |
| |
 |
| Model 43T |
|
Product Sheet
Listen |
|
|
|
|
The 43T Industrial Bell is a high performance mechanical Bell ideal for life safety applications where medium sound output, low current draw and dependable operation are of critical concern. Available in 6 inch or 10 inch gong size. Available in 120 Volt AC or 24 Volts AC, 86 to 88 dB rating
Sample Sounds of Tone Generator Module
| Tones |
Description |
|
800Hz
0.3s, silence 15s |
|
784Hz
1.25s fading |
|
770Hz
0.4s fading, 515Hz 2.75s fading |
|
60Hz
0.5s, silence 0.5s, repeat once |
|
970Hz
0.4s fading, 770Hz 0.9s fading |
|
560Hz
0.75s fading, 560Hz 2.3s fading |
|
Temporal Slow Whoop ANSI S3.41: 200-700Hz 0.5s, silence 0.5s,
repeat 3 times, silence 1.5s, repeat entire cadence |
|
860Hz
0.4s fading, 680Hz 0.4s fading, 570Hz 0.4s fading, 480Hz 2.3s
fading |
|
420-820Hz 0.4s |
|
1100/1390Hz alternating every 0.06s |
|
|
|
|
